四輥卷板機性能特點:
該機結(jie)構(gou)型(xing)式四輥式,上輥為(wei)主傳動(dong)(dong),通過(guo)(guo)減速機的輸出齒(chi)輪(lun)與上輥齒(chi)輪(lun)嚙合,為(wei)卷制板(ban)材(cai)提(ti)供(gong)扭矩;下(xia)輥作垂直升降運動(dong)(dong),通過(guo)(guo)液壓(ya)缸(gang)內的液壓(ya)油作用于活塞而獲得,以便(bian)夾緊(jin)板(ban)材(cai),為(wei)液壓(ya)傳動(dong)(dong);在(zai)下(xia)輥的兩(liang)側設有(you)側輥并沿著機架導軌作傾運動(dong)(dong),通過(guo)(guo)絲(si)(si)桿絲(si)(si)母蝸(gua)輪(lun)蝸(gua)桿傳動(dong)(dong);該機優點是板(ban)材(cai)端(duan)部預彎(wan)及卷圓(yuan)可(ke)以在(zai)同一臺(tai)設備上進行。
技術參數:
規(gui)格型號 | 卷板最大(da)厚度mm | 卷板最大寬(kuan)度mm | 卷(juan)板屈服極限Mpa | 卷板速度m/min | 滿載最(zui)小(xiao)直徑mm | 上輥(gun)直徑(jing)mm | 下輥(gun)直徑mm | 側輥直徑mm | 側輥最大行程mm | 側輥調(diao)整速度m/min | 主電機功率(lv)kw |
W12-25*2000 | 25 | 2000 | 245 | 4 | 800 | 350 | 320 | 240 | 240 | 80 | 22 |
W12-20*2500 | 20 | 2500 | 245 | 4 | 640 | 350 | 320 | 240 | 240 | 80 | 30 |
W12-30*2000 | 30 | 2000 | 245 | 4 | 1000 | 400 | 360 | 240 | 240 | 80 | 37 |
W12-25*2500 | 25 | 2500 | 245 | 4 | 800 | 400 | 360 | 240 | 240 | 80 | 37 |
W12-35*2000 | 35 | 2000 | 245 | 4 | 1200 | 420 | 380 | 210 | 210 | 80 | 37 |
W12-30*2500 | 30 | 2500 | 245 | 4 | 1000 | 400 | 360 | 230 | 230 | 80 | 37 |
W12-40*2000 | 40 | 2000 | 245 | 4 | 1400 | 480 | 400 | 420 | 420 | 80 | 45 |
W12-45*2000 | 45 | 2000 | 245 | 4 | 1600 | 500 | 450 | 280 | 280 | 80 | 45 |
W12-35*2500 | 35 | 2500 | 245 | 4 | 1200 | 480 | 400 | 420 | 420 | 80 | 45 |
W12-40*2500 | 40 | 2500 | 245 | 4 | 1400 | 500 | 450 | 380 | 380 | 80 | 45 |
W12-45*2500 | 45 | 2500 | 245 | 4 | 1600 | 530 | 480 | 450 | 450 | 80 | 63 |
W12-35*3000 | 35 | 3000 | 245 | 4 | 1200 | 500 | 450 | 380 | 380 | 80 | 45 |
W12-45*3000 | 45 | 3000 | 245 | 4 | 1600 | 560 | 500 | 450 | 450 | 80 | 63 |
W12-55*2500 | 55 | 2500 | 245 | 4 | 2000 | 600 | 550 | 500 | 500 | 78 | 75 |
W12-55*3000 | 55 | 3000 | 245 | 4 | 2000 | 620 | 560 | 500 | 500 | 78 | 75 |
W12-65*3000 | 65 | 3000 | 245 | 4 | 2400 | 670 | 600 | 550 | 550 | 78 | 110 |
