性能特點:
全鋼焊接結構,震動(dong)消除應力,機器(qi)強度高,剛性好
液壓(ya)上傳動(dong),無(wu)極(ji)調壓(ya),采用高質量進口(kou)密(mi)封圈(quan),平穩可靠
機械擋(dang)塊,扭(niu)軸(zhou)同步,精度(du)高(gao)
后擋料定位和(he)滑塊行程調(diao)(diao)節,采用電動(dong)(dong)快調(diao)(diao)和(he)手動(dong)(dong)微調(diao)(diao),數字顯示
上模配有繞(rao)度補(bu)償機構(gou)。(250噸以上為工作臺下補(bu)償機構(gou))
機床配有(you)安(an)(an)全防護欄及(ji)開(kai)門斷電裝置,提高了(le)操作(zuo)的安(an)(an)全性。
技術參數:
規格型號 Specification | 公稱壓力 Nominal Pressure | 工作臺長度 Length of working table | 喉口深度 Throat dephts | 滑塊行程 Ram Stroke | 行程次數 Number of Stroke | 主電機功率 Motor power |
KN | mm | mm | mm | m/min-1 | KW | |
WC67Y/K-40/2200 | 400 | 2200 | 200 | 100 | 11 | 4 |
WC67Y/K-40/2500 | 400 | 2500 | 200 | 100 | 11 | 4 |
WC67Y/K-50/2500 | 500 | 2500 | 200 | 100 | 11 | 5.5 |
WC67Y/K-63/2500 | 630 | 2500 | 250 | 100 | 10 | 5.5 |
WC67Y/K-63/3200 | 630 | 3200 | 250 | 100 | 10 | 5.5 |
WC67Y/K-80/2500 | 800 | 2500 | 320 | 150 | 8 | 7.5 |
WC67Y/K-80/3200 | 800 | 3200 | 320 | 150 | 8 | 7.5 |
WC67Y/K-100/2500 | 1000 | 2500 | 320 | 150 | 8 | 7.5 |
WC67Y/K-100/3200 | 1000 | 3200 | 320 | 150 | 8 | 7.5 |
WC67Y/K-100/4000 | 1000 | 4000 | 400 | 150 | 8 | 7.5 |
WC67Y/K-125/2500 | 1250 | 2500 | 320 | 150 | 8 | 7.5 |
WC67Y/K-125/3200 | 1250 | 3200 | 320 | 150 | 8 | 7.5 |
WC67Y/K-125/4000 | 1250 | 4000 | 400 | 150 | 8 | 7.5 |
WC67Y/K-160/3200 | 1600 | 3200 | 400 | 180 | 8 | 11 |
WC67Y/K-160/4000 | 1600 | 4000 | 400 | 180 | 8 | 11 |
WC67Y/K-160/5000 | 1600 | 5000 | 400 | 180 | 7 | 11 |
WC67Y/K-160/6000 | 1600 | 6000 | 400 | 200 | 7 | 15 |
WC67Y/K-200/3200 | 2000 | 3200 | 400 | 200 | 7 | 15 |
WC67Y/K-200/4000 | 2000 | 4000 | 400 | 200 | 7 | 15 |
WC67Y/K-200/6000 | 2000 | 6000 | 400 | 200 | 7 | 15 |
WC67Y/K-250/3200 | 2500 | 3200 | 400 | 200 | 7 | 18.5 |
WC67Y/K-250/4000 | 2500 | 4000 | 400 | 200 | 7 | 18.5 |
WC67Y/K-250/6000 | 2500 | 6000 | 400 | 250 | 7 | 18.5 |
WC67Y/K-300/3200 | 3000 | 3200 | 400 | 250 | 7 | 22 |
WC67Y/K-300/4000 | 3000 | 4000 | 400 | 250 | 7 | 22 |
WC67Y/K-300/6000 | 3000 | 6000 | 400 | 250 | 7 | 30 |
WC67Y/K-300/7000 | 3000 | 7000 | 400 | 250 | 7 | 30 |
WC67Y/K-400/6000 | 4000 | 6000 | 400 | 250 | 7 | 30 |
WC67Y/K-500/6000 | 5000 | 6000 | 400 | 300 | 7 | 37 |
WC67Y/K-600/6000 | 6000 | 6000 | 420 | 300 | 7 | 37 |
